Specification Details
Rated Output Power 1000W
Output Waveform Pure Sine Wave
Output Voltage 185–230VAC 50Hz
Low DC Warning Voltage 6.0Vdc
Low DC Cut-off Voltage 5.6Vdc
Low DC Return Voltage 6.2Vdc
Charging Power 1100W Max
Bulk Charging Voltage 7.2Vdc
Float Charging Voltage 7.0Vdc
AC Input
Specification Details
Nominal Input Voltage 230Vac
Low Loss Voltage 90Vac ±7
Low Loss Return Voltage 100Vac ±7
High Loss Voltage 280Vac ±7
High Loss Return Voltage 270Vac ±7
Max AC Input Voltage 300Vac
Frequency 45–65Hz
AC Charging Power 1000W Max
Solar Input
Specification Details
Nominal PV Voltage 36Vdc
MPPT Voltage Range 10–50Vdc
Max Open Circuit Voltage 60Vdc
Solar Charging Power 600W Max
Lithium Battery
Specification Details
Capacity 2009.6Wh
Nominal Battery Voltage 6.4Vdc
Typical Capacity 314Ah
Max Charge Current 220A
Max Discharge Current 220A
Operation Voltage Range 5.6–7.2Vdc
Operating Temperature -10°C ~ 50°C
DC Output
Specification Details
DC Output Power DC12V 60W Max
Ports 1 USB + 2 DC Jack (5.5×2.1mm)
Display & Protection
Feature Details
LED Indicators 4 SOC indicators + Working status indicator
Protection Overcharge, Overdischarge, Overcurrent, Short Circuit, Overtemperature
Environment
Specification Details
Noise <40dB (1 meter)
Working Temperature -10°C ~ 50°C
Humidity 0–95% (No condensation)
Sea Level ≤2000m
Dimensions
Specification Details
Product Size (L×W×H) 278×243×330 mm
Package Size (L×W×H) 526×350×212 mm
